WebSocket example

Here you'll find a tutorial to help you understand how to use WebSockets when working with the Audio Control API.

Step 1: Requirements

To follow this example, you must have Node.js installed. For more information and instructions, see and

We will also use the WebSocket Node.js library, which can be installed with npm.

Step 2: Setup

Create a new folder, open a terminal, and go to the newly created directory.

$> mkdir websocket_example
$> cd websocket_example

In the newly created directory initialize Node.js and accept defaults.

$> npm init --yes

Install the WebSocket library.

$> npm install websocket

Step 3: Get playing content info notifications

  • Create a playing_content_info.js file, and include the following code:
  • Note: you will have to change the IP address and port number in the last line. To find the {ipaddress} and {port} number see X_ScalarWebAPI_BaseURL in Discovery Process, for example, for Home Audio products the port is usually 10000 and for Personal Audio products, 54480. The {ipaddress} is the IP address of the audio product.To get the playing content info notifications, you must enable the notifyPlayingContentInfo notification via the switchNotifications method.

#!/usr/bin/env node
var WebSocketClient = require('websocket').client;
var client = new WebSocketClient();
function switchNotifications(id,disable,enable){
  return {
    "method": "switchNotifications",
    "id": id,
    "params": [{
      "disabled": disable,
      "enabled": enable
    "version": "1.0"
client.on('connectFailed', function(error) {
  console.log('Connect Error: '   error.toString());
client.on('connect', function(connection) {
  console.log('WebSocket Client Connected');
  connection.on('error', function(error) {
    console.log("Connection Error: "   error.toString());
  connection.on('close', function() {
    console.log('WebSocket Connection Closed');
  connection.on('message', function(message) {
    if (message.type === 'utf8') {
      var msg = JSON.parse(message.utf8Data);
      // Check whether the message ID equals '1', to avoid creating a loop.
      if ( == 1){
        let all_notifications = msg.result[0].disabled.concat(msg.result[0].enabled);
        var enable = [];
        var disable = [];
        // Enable only the 'notifyPlayingContentInfo' notifications.
          item => == "notifyPlayingContentInfo"
          ? enable.push(item) : disable.push(item) );
        // Use a different ID than '1', to avoid creating a loop.
      } else {
        console.log("Received: '"   message.utf8Data   "'");
  function subscribe() {
    if (connection.connected) {
      // To get current notification settings, send an empty 'switchNotifications'
      // message with an ID of '1'.

Enter the following code in the terminal or command prompt to run the code.

$> node ./playing_content_info.js

The output should be similar to the following:

WebSocket Client Connected
Received: '{"id":2,"result":[{"disabled":[{"name":"notifyAvailablePlaybackFunction","version":"1.0"},{"name":"notifyExternalTerminalStatus","version":"1.0"}],"enabled":[{"name":"notifyPlayingContentInfo","version":"1.0"}]}]}'
Received: '{"method":"notifyPlayingContentInfo","params":[{"contentKind":"input","output":"extOutput:zone?zone=1","source":"extInput:bd-dvd","uri":"extInput:bd-dvd"}],"version":"1.0"}'
Received: '{"method":"notifyPlayingContentInfo","params":[{"contentKind":"input","output":"extOutput:zone?zone=1","source":"extInput:sat-catv","uri":"extInput:sat-catv"}],"version":"1.0"}'
Received: '{"method":"notifyPlayingContentInfo","params":[{"contentKind":"input","output":"extOutput:zone?zone=2","source":"extInput:video?port=1","uri":"extInput:video?port=1"}],"version":"1.0"}'

Note: A new Received message should be posted in the terminal every time the input source is changed.
